Sequence	LED	Lens	FWHM	Phase Space Angle	Cd/Klm	Angle of Lux @ 4m	Diameter	Height
41.	Bridgelux/V-Series/V10B Gen-7	BRX_V10G7_NIO2435	24°	35°	5,582	431.4 lux	47 mm	30 mm
42.	Bridgelux/V-Series/V10B Gen-7	BRX_V10G7_NIO2636	26°	36°	4,487	365.5 lux	54 mm	27.6 mm
43.	Bridgelux/V-Series/V10B Gen-7	BRX_V10G7_NIO2939	29°	39°	4,001	325.7 lux	49 mm	25 mm
44.	Bridgelux/V-Series/V10B Gen-7	BRX_V10G7_NIO3240	32°	40°	3,398	276.9 lux	53 mm	27 mm
45.	Bridgelux/V-Series/V10B Gen-7	BRX_V10G7_NIO5068	50°	68°	1,308	106 lux	37 mm	16 mm
46.	Bridgelux/V-Series/V10B Gen-7	BRX_V10G7_NIO6275	62°	75°	828	62 lux	27 mm	12 mm
47.	Bridgelux/V-Series/V13 Gen-6 pm	BRX_V13G6_NIO2736_pm	27°	36°	4,472	584.3 lux	56 mm	31 mm
48.	Bridgelux/V-Series/V13 Gen-6 pm	BRX_V13G6_NIO2738_pm	27°	38°	4,054	529.6 lux	53 mm	32 mm
49.	Bridgelux/V-Series/V13 Gen-6 pm	BRX_V13G6_NIO3041_pm	30°	41°	92	473.3 lux	51 mm	28 mm
50.	Bridgelux/V-Series/V13 Gen-6 pm	BRX_V13G6_NIO3548_pm	35°	48°	2,634	344 lux	50 mm	27.7 mm
51.	Bridgelux/V-Series/V13 Gen-6 pm	BRX_V13G6_NIO3551_pm	35°	51°	2,647	343.4 lux	49 mm	25 mm
52.	Bridgelux/V-Series/V13 Gen-6 pm	BRX_V13G6_NIO4258_pm	42°	58°	1,646	214.8 lux	37 mm	16 mm
53.	Bridgelux/V-Series/V13 Gen-6 pm	BRX_V13G6_NIO4972_pm	49°	72°	1,201	156.6 lux	36.5 mm	14 mm
54.	Bridgelux/V-Series/V13 Gen-6 pm	BRX_V13G6_NIO5675_pm	56°	75°	979	124.5 lux	39 mm	15 mm
55.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO2635_Si	26°	35°	4,814	628.9 lux	56 mm	31 mm
56.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO2636_Si	26°	36°	4,597	600.5 lux	53 mm	32 mm
57.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO2940_Si	29°	40°	3,623	502,3 lux	51 mm	28 mm
58.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO3445_Si	34°	45°	2,893	377.9 lux	50 mm	27.7 mm
59.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO3545_Si	35°	45°	2,709	346.5 lux	55 mm	33 mm
60.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO3350_Si	33°	50°	2,647	354.5 lux	49 mm	25 mm
