Sequence	LED	Lens	FWHM	Phase Space Angle	Cd/Klm	Angle of Lux @ 4m	Diameter	Height
61.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO4160_Si	41°	60°	1,702	221.6 lux	37 mm	16 mm
62.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO4770_Si	47°	70°	1,263	165 lux	36.5 mm	14 mm
63.	Bridgelux/V-Series/V13 Gen-6 Si	BRX_V13G6_NIO5575_Si	55°	75°	1,020	131.5 lux	39 mm	15 mm
64.	Bridgelux/V-Series/V13B Gen-7	BRX_V13G7_NIO2835_Si	28°	35°	4,070	565.1 lux	56 mm	31 mm
65.	Bridgelux/V-Series/V13B Gen-7	BRX_V13G7_NIO2941_Si	29°	41°	3,581	497.2 lux	53 mm	32 mm
66.	Bridgelux/V-Series/V13B Gen-7	BRX_V13G7_NIO3245_Si	32°	45°	3,104	430.2 lux	51 mm	28 mm
67.	Bridgelux/V-Series/V13B Gen-7	BRX_V13G7_NIO3850_pm	38°	50°	2,324	322.7 lux	50 mm	27.7 mm
68.	Bridgelux/V-Series/V13B Gen-7	BRX_V13G7_NIO3853_pm	38°	53°	2,238	305.5 lux	49 mm	25 mm
69.	Bridgelux/V-Series/V13B Gen-7	BRX_V13G7_NIO4664_pm	46°	64°	1,374	190.5 lux	37 mm	16 mm
70.	Bridgelux/V-Series/V13B Gen-7	BRX_V13G7_NIO5577_pm	55°	77°	1,005	139.3 lux	36.5 mm	14 mm
71.	Bridgelux/V-Series/V13B Gen-7	BRX_V13G7_NIO6179_pm	61°	79°	832	114.3 lux	39 mm	15 mm
72.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO2334	23°	34°	5,853	1,112.1 lux	72 mm	41 mm
73.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO2938	29°	38°	3,934	747.5 lux	69 mm	39 mm
74.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO3445	34°	45°	90	560.4 lux	56 mm	33 mm
75.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO3750	37°	50°	2,359	448.2 lux	50 mm	27.7 mm
76.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO4055	40°	55°	2,191	416.3 lux	66 mm	32.5 mm
77.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO4663	46°	63°	1,609	305.7 lux	60 mm	26.5 mm
78.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO5168	51°	68°	1,278	242 lux	50 mm	23 mm
79.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO5875	58°	75°	967	183.3 lux	47 mm	20 mm
80.	Bridgelux/V-Series/V15 Gen-6	BRX_V15_NIO6080	60°	80°	874	162.2 lux	43.5 mm	17 mm
