Sequence	LED	Lens	FWHM	Phase Space Angle	Cd/Klm	Angle of Lux @ 4m	Diameter	Height
81.	Bridgelux/V-Series/V18 Gen-6	BRX_V18G6_NIO2232	22°	32°	5,998	1,347.5 lux	84 mm	45.75 mm
82.	Bridgelux/V-Series/V18 Gen-6	BRX_V18G6_NIO2536	25°	36°	4,942	1,110.2 lux	83 mm	49 mm
83.	Bridgelux/V-Series/V18 Gen-6	BRX_V18G6_NIO2840	28°	40°	3,847	858 lux	72 mm	41 mm
84.	Bridgelux/V-Series/V18 Gen-6	BRX_V18G6_NIO3242	32°	42°	2,953	661.5 lux	72 mm	41.75 mm
85.	Bridgelux/V-Series/V18 Gen-6	BRX_V18G6_NIO3245	32°	45°	2,997	671.3 lux	69 mm	39 mm
86.	Bridgelux/V-Series/V18 Gen-6	BRX_V18G6_NIO3850	38°	50°	2,166	482.2 lux	61 mm	30 mm
87.	Bridgelux/V-Series/V18 Gen-6	BRX_V18G6_NIO4460	44°	60°	1,642	368.6 lux	59 mm	26 mm
88.	Bridgelux/V-Series/V18 Gen-6	BRX_V18G6_NIO5170	51°	70°	1,259	281.5 lux	61 mm	26.5 mm
89.	Bridgelux/V-Series/V18B Gen-7	BRX_V18G7_NIO2335	23°	35°	5,644	1,568.3 lux	84 mm	45.75 mm
90.	Bridgelux/V-Series/V18B Gen-7	BRX_V18G7_NIO2638	26°	38°	4,654	1,293 lux	83 mm	49 mm
91.	Bridgelux/V-Series/V18B Gen-7	BRX_V18G7_NIO2941	29°	41°	3,591	996 lux	72 mm	41 mm
92.	Bridgelux/V-Series/V18B Gen-7	BRX_V18G7_NIO3343	33°	43°	2,774	768.7 lux	72 mm	41,75 mm
93.	Bridgelux/V-Series/V18B Gen-7	BRX_V18G7_NIO3345	33°	45°	2,807	778.9 lux	69 mm	39 mm
94.	Bridgelux/V-Series/V18B Gen-7	BRX_V18G7_NIO3955	39°	55°	2,010	553.8 lux	61 mm	30 mm
95.	Bridgelux/V-Series/V18B Gen-7	BRX_V18G7_NIO4565	45°	65°	1,552	429.8 lux	59 mm	26 mm
96.	Bridgelux/V-Series/V18B Gen-7	BRX_V18G7_NIO5270	52°	70°	1,205	333.5 lux	61 mm	26.5 mm
97.	Bridgelux/V-Series/V22 Gen-6	BRX_V22G6_NIO2336	23°	36°	5,923	2,258.1 lux	98 mm	58.5 mm
98.	Bridgelux/V-Series/V22 Gen-6	BRX_V22G6_NIO2738	27°	38°	4,942	1,883.9 lux	101 mm	58 mm
99.	Bridgelux/V-Series/V22 Gen-6	BRX_V22G6_NIO2744	27°	44°	4,207	1,596.9 lux	86 mm	49 mm
100.	Bridgelux/V-Series/V22 Gen-6	BRX_V22G6_NIO3349	33°	49°	2,802	1,068.1 lux	90 mm	45 mm
