Sequence	LED	Lens	FWHM	Phase Space Angle	Cd/Klm	Angle of Lux @ 4m	Diameter	Height
101.	Bridgelux/V-Series/V22 Gen-6	BRX_V22G6_NIO3755	37°	55°	2,417	921.5 lux	85 mm	40 mm
102.	Bridgelux/V-Series/V22 Gen-6	BRX_V22G6_NIO4460	44°	60°	1,699	642 lux	85.5 mm	42.6 mm
103.	Bridgelux/V-Series/V22 Gen-6	BRX_V22G6_NIO5575	55°	75°	1,047	392.7 lux	60 mm	27 mm
104.	Bridgelux/V-Series/V22 Gen-6	BRX_V22G6_NIO6588	65°	88°	723	275.1 lux	70 mm	24 mm
105.	Bridgelux/V-Series/V22B Gen-7	BRX_V22G7_NIO2335	23°	35°	5,661	3,014.3 lux	98 mm	58.5 mm
106.	Bridgelux/V-Series/V22B Gen-7	BRX_V22G7_NIO2737	27°	37°	4,840	2,577 lux	101 mm	58 mm
107.	Bridgelux/V-Series/V22B Gen-7	BRX_V22G7_NIO2642	26°	42°	4,137	2,196.5 lux	86 mm	49 mm
108.	Bridgelux/V-Series/V22B Gen-7	BRX_V22G7_NIO3349	33°	49°	2,745	1,461.8 lux	90 mm	45 mm
109.	Bridgelux/V-Series/V22B Gen-7	BRX_V22G7_NIO3653	36°	53°	2,358	1,255.8 lux	85 mm	40 mm
110.	Bridgelux/V-Series/V22B Gen-7	BRX_V22G7_NIO4360	43°	60°	1,683	890.1 lux	85.5 mm	42.6 mm
111.	Bridgelux/V-Series/V22B Gen-7	BRX_V22G7_NIO5574	55°	74°	1,020	536.9 lux	60 mm	27 mm
112.	Bridgelux/V-Series/V22B Gen-7	BRX_V22G7_NIO6587	65°	87°	695	369.1 lux	70 mm	24 mm
113.	Bridgelux/V-Series/V6 A	BRX_V6G6a_NIO1625	16°	25°	11,625	261.5 lux	46 mm	30 mm
114.	Bridgelux/V-Series/V6 A	BRX_V6G6a_NIO2335	23°	35°	5,332	119.3 lux	37 mm	17.7 mm
115.	Bridgelux/V-Series/V6 A	BRX_V6G6a_NIO2536	25°	36°	4,634	103.7 lux	33 mm	17 mm
116.	Bridgelux/V-Series/V6 A	BRX_V6G6a_NIO3044	30°	44°	3,417	76.5 lux	29 mm	13.6 mm
117.	Bridgelux/V-Series/V6 A	BRX_V6G6a_NIO3855	38°	55°	2,134	47.7 lux	29 mm	12.6 mm
118.	Bridgelux/V-Series/V6 A	BRX_V6G6a_NIO5273	52°	73°	1,166	25.9 lux	27 mm	9.8 mm
119.	Bridgelux/V-Series/V6 B	BRX_V6G6b_NIO1625	16°	25°	11,743	267.8 lux	46 mm	30 mm
120.	Bridgelux/V-Series/V6 B	BRX_V6G6b_NIO2535	25°	35°	4,593	104.7 lux	33 mm	17 mm
